Part number 14001-AK055. A ball bearing turbocharger from the HKS GT series, targeting the 1000ps range. The compressor housing carries a highly corrosion-resistant anodised aluminium coating in matt black, with a bell mouth ported shroud finished in champagne gold alumite. The stainless steel exhaust housing uses a T4 inlet flange and V-band outlet. HKS developed the GT75100 as a step up from the T51R SPL.BB, with ideal performance on the RB26 (2.8L) and 2JZ (3.4L).
Key Features
- Ball bearing centre section
- Target power range of 1000ps
- Bell mouth ported shroud in champagne gold alumite
- Matt black anodised, corrosion-resistant aluminium compressor housing
- Stainless steel exhaust housing
- Developed for the RB26 (2.8L) and 2JZ (3.4L)
Specifications
- Series: GT (GT75100 BB)
- Compressor wheel: 73mm inducer, 91mm exducer, 65 trim
- Turbine wheel: 75mm exducer, 82mm inducer, 84 trim
- Compressor housing: 101.6mm inlet, 76.2mm outlet, A/R 0.90
- Exhaust housing: T4 inlet flange, V-band outlet, A/R 1.01
