Designed and manufactured in house by WOSPerformance, these super-efficient units are based around the latest generation of alternator technology. These race proven compact alternators offer the best size and power / weight ratio available, and at far lower rpm than alternatives, due to a patented design which enables them to deliver up to 80% of maximum output at average idle speeds – catering for the large electrical loads usually found at this time.
WOSPerformance build these as high output, low rpm, application specific 'fit and forget' direct replacement OE units.
Please note high output alternators require more rpm to charge and become less efficient at idle / low rpm.
Specification
| Output |
250A |
| Voltage |
12V |
| Polarity |
-VE |
| Connection |
B+ / IG / C / L / FR |
| Construction |
Cast |
| Mounting |
R/H |
| Lugs |
2 |
| Pulley |
LMP138 |
| Weight |
5.3Kg / 11.71lbs |
Vehicle Applications
- Honda Civic 1.4 / 1.6 Petrol D14Z5 / D14Z6 / D16W7 / D16V1 Mk VII (EP1 / EP2 / ES4 / ES5 / EU5 / EU6 / EU7 / EU8) '00-'05
- Honda Civic Coupe 1.7 Petrol D17A5 / D17A8 / D17A9 Mk VII (EM2) '01-'05
- Honda FR-V 1.7 Petrol D17A2 (BE1) '04-'06
OE Cross Reference
Built to order by WOSPerformance in the UK.
