Designed and manufactured in house by WOSPerformance, these super-efficient units are based around the latest generation of alternator technology. These race proven compact alternators offer the best size and power / weight ratio available, and at far lower rpm than alternatives, due to a patented design which enables them to deliver up to 80% of maximum output at average idle speeds – catering for the large electrical loads usually found at this time.
WOSPerformance build these as high output, low rpm, application specific 'fit and forget' direct replacement OE units.
Specification
| Output |
120A |
| Voltage |
12V |
| Polarity |
-VE |
| Connection |
B+ / IG / C / L / FR |
| Construction |
Cast |
| Mounting |
R/H |
| Lugs |
2 |
| Pulley |
LMP138 |
| Weight |
5.3Kg / 11.71lbs |
Vehicle Applications
- Honda Civic 1.4 / 1.6 Petrol D14Z5 / D14Z6 / D16W7 / D16V1 Mk VII (EP1 / EP2 / ES4 / ES5 / EU5 / EU6 / EU7 / EU8) '00-'05
- Honda Civic Coupe 1.7 Petrol D17A5 / D17A8 / D17A9 Mk VII (EM2) '01-'05
- Honda FR-V 1.7 Petrol D17A2 (BE1) '04-'06
OE Cross Reference
Built to order by WOSPerformance in the UK.
