A bundle combining the 2-port turbo heat shield, air oil separator, and resonator delete for the 2020 B58 GR Supra. All three components are located in the same area of the engine bay, making this a practical combined fit.
Note: this bundle is specifically for 2020 GR Supra models with the 2-port manifold (3.0L only). For 2021+ 6-port models, a separate bundle is available.
Turbo heat shield
Designed from internal scan data for an OEM-style fit over the turbine housing area. Produced from 2.0mm 304 stainless steel, CNC laser cut and press brake formed, finished in high-temp Cerakote. Available in black or titanium Cerakote.
Air oil separator
Prevents blow-by from entering the intake system. Oil in the intake reduces octane, which can lead to detonation, power loss, and carbon build-up. Features 4 x 5-micron coalescent filters, baffling, and stainless mesh. Supplied with specifically moulded silicone hoses.
Includes
- 2-port turbo heat shield kit
- Air oil separator
- Resonator delete
Heat shield specifications
- Material: 2.0mm 304 stainless steel
- Finish: high-temp Cerakote (black or titanium)
- CNC laser cut and press brake formed
- Hardware: stainless steel throughout
