HKS Intercooler Kit Subaru Impreza GRB R type Intercooler

Features

From the performance improvement of genuine I / C, use R type core with large capacity + low pressure loss.

The side tank is a shape that allows air to effectively use the core bumper opening from I / C entrance to exit.

Piping layout minimized bending R as much as possible, minimizing deterioration of response due to preliminary installation.
As a result, the supercharging pressure rising equivalent to the original I / C was realized.

With genuine I / C, the core accumulates heat when the hot air in the E / G room stops, and knocking tends to occur at the start.
By prefixing the I / C, it suppresses the occurrence of knocking at start and supports ""unbreakable tuning"".

Core size (600 × 255.6 × 103), genuine (170 × 525 × 65)

Even with genuine ECU specifications, performance improvement is possible, but higher performance can be obtained by setting with F-CON iS / Vpro etc.

Component Structure

Core ASSY

Rtype core (side tank buff finish)

Inlet pipe

Three (Aluminum buff finish)

Outlet pipe

Three (Aluminum buff finish)

Hose

Silicone hose

Other

Bracket stepping on

Test vehicle

Car name

Impreza WRX STI

Model

GRB

Engine model

EJ207

Mission

6MT

Scarf

LEGAMAX Premium

Other exhaust system

Metal catalyzer + center pipe

air cleaner

Racing Suction R

ECU

F-CON iS

Boost pressure control

EVC (140 kPa)

Attention point on installation

Processing to bumper, change of battery size (B19L size) is required for installation.

Can not be used with genuine recycling valve, SQV can be installed. (SQV general purpose flange is welded to pipe)

Separately racing suction reloaded is required.

Although ECU setting is not necessary when intake / exhaust system tuning, more effect is demonstrated by setting.
We recommend setting with F-CON iS, V Pro, etc. to enhance the effect more than boost-up car.

Reference installation time: 5-6 hours

Car model

Model

engine

Model year

type

Core size / mm · Mounting position

type

Code No.

Retail price
(excluding tax)

Remarks

Impreza

GRB

EJ207

07 / 10-14 / 08

R type INTERCOOLER

600 X 255.6 X 102 · Introduction

R type AL

13001-AF014

¥ 213,840 ( ¥ 198,000)

Genuine recycling installation impossible, battery size change necessary (B19L), separately racing suction reloaded (70020-AF010) required
